IEEE PC37.114

Revision Standard - Active - Draft.
Electrical faults on transmission and distribution lines are detected and isolated by system protective devices. Once the fault has been cleared, outage times can be reduced if the location of the fault can be determined more quickly. The techniques and application considerations for determining the location of a fault on ac transmission and distribution lines are outlined in this guide. Traditional approaches and the primary measurement techniques used in modern devices are reviewed: one- and two-terminal impedance-based methods and traveling-wave methods. Application considerations include: two- and three-terminal lines, series-compensated lines, parallel lines, untransposed lines, underground cables, fault resistance effects, and other power system conditions, including those unique to distribution systems.

This guide outlines the techniques and application considerations for determining the location of a fault on ac transmission and distribution lines. Application considerations include but are not limited to: Multi-terminal lines, series-compensated lines, parallel lines, untransposed lines, tapped lines, underground cables, fault resistance effects, and other power system conditions, including those unique to distribution systems.
This document reviews various approaches of calculating a fault location, including impedance-based methods, synchronized measuring methods, and traveling wave methods. It is meant to assist power system engineers and operators in applying fault location techniques on their systems. Users learn the strengths and limitations of measurement data and when further analysis is required using additional methods and when more data must be gathered. The guide assists in calculating fault location and therefore faster restoration of power systems through improved understanding of fault location techniques.
