IEEE C57.19.00:2004 (R2010)

Revision Standard - Inactive-Reserved.
This standard applies to power apparatus bushings that have basic impulse insulation levels of 110 kV and above for use as components of oil-filled transformers and oil-filled reactors. Keywords: apparatus bushings, bushings, oil-filled reactors, oil-filled transformers

This standard applies to power apparatus bushings that have basic impulse insulation levels of 110 kV and above for use as components of oil-filled transformers and oil-filled reactors. This standard does not apply to the following:
-- High-voltage cable terminations (potheads)
-- Bushings for oil circuit breakers
-- Bushings for instrument transformers
-- Bushings for test transformers
-- Bushings in which the internal insulation is provided by a gas
-- Bushings applied with gaseous insulation (other than air at atmospheric pressure) external to the bushing
-- Bushings for distribution-class circuit breakers and transformers
-- Bushings for automatic circuit reclosers and line sectionalizers
-- Bushings for oil-less and oil-poor apparatus
-- Bushings for dc applications
This standard defines the special terms used, service conditions, rating, general requirements, and test procedure for apparatus bushings. See IEEE Std C57.19.01™ for specific listings of values of electrical and mechanical characteristics, dimensions, and other related requirements that are defined or described in this standard.
