IEEE C37.90.1:2024

Revision Standard - Active - Draft.


This standard specifies design tests for relays, relay systems, and control devices used for Protection and Control of Electric Power Apparatus, that relate to the immunity of this equipment to repetitive electrical transients. Two types of tests are specified, the slow damped oscillatory (SWC) and electrical fast transient burst (EFT) tests. For devices with communication ports, where the device does not perform protection or control functions, testing of the communication functions is covered by IEEE Standard 1613. Where the device performs protection or control functions and has communication ports, tests for all communication functions are covered by this document. For devices without communication ports, the tests are covered by this document.
This standard establishes a common and reproducible basis for evaluating the performance of relays, relay systems, and control devices used for Protection and Control of Electric Power Apparatus, when subjected to repetitive transients on supply, signal, control, and communication lines or connections. This standard establishes that an evaluation is performed during both normal (non-tripped) and abnormal (tripped) relay operating conditions.
