IEEE C37.06.1:2017
IEEE Recommended Practice for Preferred Ratings for High-Voltage(>1000 volts) AC Circuit Breakers Designated Definite Purpose for Fast Transient Recovery Voltage Rise Times
Summary
New IEEE Standard - Active.
The preferred ratings of transformer-limited fault duty (fast transient recovery voltage rise times) of indoor and outdoor high-voltage circuit breakers rated above 1000 V for use in commercial, industrial, and utility installations are described.
This recommended practice is issued as a supplement to IEEE Std C37.06 for high-voltage circuit breaker applications where the transient recovery voltage (TRV) peak is higher and/or its rise to the crest value occurs more rapidly than those specified in IEEE Std C37.06.
The purpose of this document is to introduce transformer-limited faults, similar to that established by IEEE Std C37.016 [B5], and specifically to provide preferred values for standard ratings of fast transient referred to as transformer-limited fault recovery voltage rise times and to introduce a transformer-limited fault (TLF) breaking current.
The preferred ratings of transformer-limited fault duty (fast transient recovery voltage rise times) of indoor and outdoor high-voltage circuit breakers rated above 1000 V for use in commercial, industrial, and utility installations are described.
This recommended practice is issued as a supplement to IEEE Std C37.06 for high-voltage circuit breaker applications where the transient recovery voltage (TRV) peak is higher and/or its rise to the crest value occurs more rapidly than those specified in IEEE Std C37.06.
The purpose of this document is to introduce transformer-limited faults, similar to that established by IEEE Std C37.016 [B5], and specifically to provide preferred values for standard ratings of fast transient referred to as transformer-limited fault recovery voltage rise times and to introduce a transformer-limited fault (TLF) breaking current.
Notes
Active
Technical characteristics
| Publisher | Institute of Electrical and Electronics Engineers (IEEE) |
| Publication Date | 02/06/2018 |
| Cancellation Date | 02/06/2018 |
| Edition | |
| Page Count | 26 |
| EAN | --- |
| ISBN | --- |
| Weight (in grams) | --- |
| Brochures |
|
