Active
, Confirmed
Standard
Most Recent
ASME Y14.5M-1994 (R2004)
Dimensioning and Tolerancing
Summary
There is a newer edition of this document available. The Y14.5M standard establishes uniform practices for stating and interpreting dimensioning, tolerancing, and related requirements for use on engineering drawings and in related documents. [Geometric Dimensioning and Tolerancing (GD&T)] For a mathematical explanation of many of the principles in this standard, see ASME Y14.5.1M. Practices unique to architectural and civil engineering, land, welding symbology are not included.
Technical characteristics
| Publisher | American Society of Mechanical Engineers (ASME) |
| Publication Date | 01/01/1994 |
| Release Date | 01/23/1995 |
| Confirmation Date | 01/01/2004 |
| Edition | 1994 |
| Page Count | 252 |
| Themes | Drafting |
| EAN | --- |
| ISBN | --- |
| Weight (in grams) | --- |
No products.
Previous versions
