Active
Standard
Most Recent
ASME Y14.24-2020
Types and Applications of Engineering Drawings
Summary
This Standard defines the types of engineering drawings most frequently used to establish engineering requirements. It describes typical applications and minimum content requirements. Drawings for specialized engineering disciplines (e.g., marine, civil, construction, optics, etc.) are not included in this Standard.
Technical characteristics
| Publisher | American Society of Mechanical Engineers (ASME) |
| Publication Date | 01/01/2020 |
| Release Date | 10/23/2020 |
| Edition | 2020 |
| Page Count | 93 |
| Themes | Drafting |
| EAN | --- |
| ISBN | --- |
| Weight (in grams) | --- |
| Brochures |
|
No products.
Previous versions
01/01/1999
Superseded
, Confirmed
Historical
