ASME Y14.2-2008
Line Conventions and Lettering
Summary
There is a newer edition of this document available. This standard establishes the line and lettering practices for use in the preparation of engineering drawings, including the recognition of the requirements for CAD (Computer Aided Design) and manual preparation for their reduction and reproduction. Y14.2 is a replacement of Y14.2M.
Technical characteristics
| Publisher | American Society of Mechanical Engineers (ASME) |
| Publication Date | 01/01/2008 |
| Release Date | 12/03/2008 |
| Edition | 2008 |
| Page Count | 20 |
| Themes | Computer Aided Design (CAD) |
| EAN | --- |
| ISBN | --- |
| Weight (in grams) | --- |
