Superseded
, Confirmed
Standard
Historical
ASME Y14.100-2004 (R2009)
Engineering Drawing Practices
Summary
There is a newer edition of this document available. This Standard establishes the essential requirements and reference documents applicable to the preparation and revision of engineering drawings and associated lists. It is essential that this Standard be used in close conjunction with ASME Y14.24, ASME Y14.34M, and ASME Y14.35M. Y14.100 is a replacement of Y14.100M.
Technical characteristics
| Publisher | American Society of Mechanical Engineers (ASME) |
| Publication Date | 01/01/2004 |
| Release Date | 09/06/2005 |
| Confirmation Date | 01/01/2009 |
| Edition | 2004 |
| Page Count | 44 |
| Themes | Drafting |
| EAN | --- |
| ISBN | --- |
| Weight (in grams) | --- |
No products.
Previous versions
01/01/2004
Superseded
, Confirmed
Historical
