Active
, Confirmed
Standard
Most Recent
ASME B18.2.1-2012 (R2021) + ERRATA
Square, Hex, Heavy Hex, and Askew Head Bolts and Hex, Heavy Hex, Hex Flange, Lobed Head, and Lag Screws (Inch Series)
Summary
This Standard covers the complete general and dimensional data for nine product types of inch series square and hex bolts and screws. Hex flange head and lobed head designs are new in this revision, as are screw sizes 1 5/8, 1 7/8, and 3 1/8 through 6 inches. Appendices covering gages and gaging information plus formulas on which dimensional data are based are included. Heavy hex structural bolts, formerly covered in ANSI B18.2.1, are now covered in ASME B18.2.6.
Technical characteristics
| Publisher | American Society of Mechanical Engineers (ASME) |
| Publication Date | 01/01/2012 |
| Release Date | 04/24/2013 |
| Confirmation Date | 01/01/2021 |
| Edition | 2012 |
| Page Count | 44 |
| Themes | Assembly |
| EAN | --- |
| ISBN | --- |
| Weight (in grams) | --- |
| Brochures |
|
No products.
Previous versions
01/01/2012
Active
, Confirmed
Most Recent
